- 1 x 520 Watt LED luminaire with driver
- 1 x Power Cable
- 1 x 3m signal cable
- 2 x Adjustable Pulley Kit
- 2 x Fixed Suspension Kit
01 — Description
Présentation du produit
The “Pure Led PRO 520W” is a latest generation LED panel designed for indoor cultivation. It has a combination of diodes with different spectrums, for a light very similar to that emitted by the sun. It thus offers exceptional light efficiency. It is manufactured by the Pure Led brand and has a power of 520W.
Quiet cooling
The passive cooling system helps to effectively remove heat without causing noise, ensuring quiet operation.
Light control
Thanks to its dimming function, it is possible to regulate the power of the light according to the needs of your crop, from seed germination to the bud maturation phase. It is also possible to connect several luminaires to the same device to control switching on and off, imitate sunrise and sunset, or for automatic shutdown in the event of an emergency or overheating.
Technical characteristics
The "Pure Led PRO 520W" uses high quality LED diodes to emit full spectrum light. These diodes emit wavelengths of light that are particularly beneficial for plant growth, especially during flowering and fruiting periods.
The LED panel is powered by a control box that allows you to adjust the light intensity and program light cycles according to the growth stage of the plants.
| Characteristic | Value |
|---|---|
| Consumption (at 100%) | 520W (+/-5%) |
| PPF | 1507.9 mol/s |
| Yield | 2.88 mol/D |
| Size | 915 x 900 x 80mm |
| Weight | 11.5kg |
| Input voltage | AC, 100-277V, 50/60Hz |
| Light source/diode type | Samsung LM281B+ Pro (2141 pcs), Honglitronics SMD 3535 (108 pcs) |
| Beam angle | 120º |
Content
The Pure Led Pro V2.0 from Pure Factory is manufactured by a brand renowned for the quality of its products. So you can buy it with confidence to get the best indoor growing results. Package contents include:
Advantages of the Pureled PRO 520W
Using "Pure Led PRO 520W" lighting has several advantages over using fluorescent lamps or incandescent lamps. First, LEDs use less energy and produce less heat, which helps reduce running costs and prevent overheating plants.
By choosing the Pure LED Pro V2.0 for your indoor cultivation, you are opting for performance, versatility and quality. It is designed to give you the best results while reducing energy costs. Order now to get your Pro V2.0 LED Lighting and experience for yourself the stunning results it can deliver. With easy installation, a long lifespan and a quality guarantee, you can be sure you have made the right choice for your indoor cultivation. Enjoy fast delivery and our dedicated customer service to answer all your questions. Order now and grow your plants like never before with the Pure LED Pro V2.0 from Pure Factory.
Conclusion
The "Pure Led PRO 520W" is an efficient and economical LED lighting solution for indoor growing. With its high-quality LED diodes and programmable control box, it allows you to control plant growth conditions and maximize crop yields.
Questions about Pure Led PRO V2.0 lighting - 520W
Is this fixture dimmable?
Yes, this LED lamp is dimmable. It is possible to regulate the light power with 5 different types, 0 %-25% -50 %-75% -100%
Is this fixture silent?
Yes, thanks to its passive ventilation system, it effectively eliminates heat without causing noise.
Can I connect several lights together?
Yes, it is possible to connect several lights to the same device to control switching on and off, imitate sunrise and sunset, or even for automatic shutdown in case of emergency or overheating.
02 — Fiche technique
Caractéristiques détaillées
| Coverage area | 120 x 120cm |
| Functions | Dimmer and Console Compatibility |
| Waterproof | Yes |
| Thermal management | Passive - Completely silent |
| Power | Between 500W and 600W |
03 — Avis clients
Customer reviews
Comments All reviews
L'installation s'est faite rapidement et sans souci. Le panneau reste froid et silencieux, ce qui est vraiment agréable durant les longues sessions. La lumière est douce, parfaite pour un confort visuel optimal. Bon rapport qualité-praticité selon moi.
Recommended to buy: Yes
Pas trop calé en matos, mais je trouve ce modèle super simple à monter et à régler. Ça chauffe pas et ça fait zéro bruit, c'est top quand je passe du temps dans ma pièce. Le prix est correct pour la qualité, franchement content de mon achat.
Recommended to buy: Yes
Reçu en parfait état, montage super simple. J'apprécie surtout le silence du panneau, ça change des vieux modèles bruyants. On sent que la qualité est là, hâte de voir les résultats sur le long terme.
Recommended to buy: Yes
Très bon panneau LED, la lumière est homogène et puissante sur ma surface de culture. Le spectre complet est vraiment un plus. Je recommande.
Recommended to buy: Yes
04 — Questions sur ce produit
Product questions
Your questions about this product
- Is it possible to use this Pure LED Pro V2.0 520W panel with a long-duration programming system to automatically adjust the brightness and simulate a natural day/night cycle in order to optimize the continuous blooming of my indoor orchids?Yes, the Pure LED Pro V2.0 520W panel can definitely be paired with a programming system that automatically adjusts brightness. It offers light intensity management and can simulate day/night cycles, including sunrise and sunset effects, which is ideal for recreating a natural cycle and promoting the continuous blooming of your indoor orchids.
- Compatible with home automation management protocol such as Modbus or ZigBee for integration into an automated system?The Pure LED Pro V2.0 520W is not designed to be compatible with home automation protocols such as Modbus or ZigBee. No technical information indicates a possible integration into such an automated system. This panel is mainly focused on the quality and reliability of lighting for indoor cultivation. If you are looking for a solution with home automation management, we can guide you towards other suitable options.
- How does the light spectrum of this Pure LED Pro 520W panel compare to the specific needs of plants during the flowering and fruiting phases in hydroponics?
The Pure LED Pro V2.0 520W uses Samsung LM281B+ Pro and Honglitronics SMD 3535 diodes, offering a full light spectrum suitable for plant needs, including in hydroponics. During the flowering and fruiting phases, plants benefit from a spectrum rich in red (660-700 nm) and blue (400-500 nm) wavelengths to stimulate flower and fruit production. This panel meets these requirements well, even if the precise spectrum details are not disclosed.
To make the most of the spectrum during flowering, it is recommended to adjust the panel height between 20 and 60 cm to optimize light intensity without risking burning the plants. This flexibility, combined with low heat output and excellent energy efficiency, makes the Pure LED Pro an excellent choice for your indoor hydroponic cultivation.
- How does the dimming system of the Pure LED Pro V2.0 520W optimize the management of growth phases during a SCROG cultivation under LED?
The dimming system of the Pure LED Pro V2.0 520W allows for precise adjustment of light intensity across five levels (0%, 25%, 50%, 75%, 100%), making it easier to adapt the light to the different phases of SCROG cultivation, from vegetative growth to flowering. Its full spectrum mimics natural light, thereby optimizing plant development at every stage.
Additionally, the integrated control box offers the possibility to program light cycles, allowing for fine management of lighting timings according to the specific needs of the plants. The absence of fans due to passive thermal dissipation ensures a stable, quiet, and energy-efficient environment, ideal for a controlled SCROG.
- Compatible with home automation integration like MQTT or API for advanced remote control and automation?
The Pure LED Pro V2.0 520W offers integrated control via a proprietary controller to locally adjust intensity (5 levels) and manage schedules as well as safety functions. It also allows for daisy chaining multiple lamps for grouped management.
However, this LED panel does not have native connectivity or compatibility with standard home automation protocols like MQTT or an API for advanced remote automation. Any integration into a home automation system would require an external device to control the hardware.
- Does this panel really live up to its promises with a failure-free operation and no power drop after 6 months of intensive use?
The Pure LED Pro V2.0 520W is equipped with high-end components such as Samsung LM281B+ Pro LEDs and features an IP65 protection rating, which gives it robustness and consistent performance. Its fanless design minimizes mechanical risks, ensuring silent and durable operation.
However, while its specifications guarantee great reliability and good longevity, there is no independent data or user feedback that formally confirms a total absence of failures or power drops after 6 months of intensive use. It remains a serious choice for stable and efficient indoor cultivation.
- What is the ideal coverage area of the Pure LED Pro V2.0 520W panel to maximize production while avoiding shadow areas in indoor cultivation?For the Pure LED Pro V2.0 520W panel, the ideal coverage area is 120 x 120 cm. This surface allows for a homogeneous distribution of light, optimizing growth and blooming without creating shadow areas. Thanks to its multi-bar system, dimmable function, and silent passive ventilation, this panel ensures a constant light intensity and excellent thermal management - perfect conditions to maximize production in indoor cultivation.
- What is the difference in luminous efficacy between this Pure LED Pro 520W panel and a standard LED panel with active cooling?The Pure LED Pro V2.0 520W boasts an impressive luminous efficacy of 2.88 µmol/J, meaning it generates more useful photosynthetic light per watt consumed compared to a standard LED panel with active cooling. These typically offer an efficacy between 2.2 and 2.5 µmol/J in the mid-range version, sometimes reaching up to 2.7-2.8 µmol/J for the higher-end models, but rarely more.
In short, the Pure LED Pro V2.0 offers about 0.4 to 0.7 µmol/J of luminous efficacy gain. This surplus translates to better plant growth while optimizing electricity consumption. It is an ideal choice for high-quality indoor lighting that is cost-effective in the long term.
- How can I integrate this Pure LED Pro 520W panel into an automation system to adjust the intensity and lighting cycles via a single centralized interface?
The Pure LED Pro V2.0 520W panel allows for intensity adjustment via a control box providing 5 dimming levels (0, 25, 50, 75, 100%) and can synchronize multiple panels to manage lighting cycles (sunrise/sunset, automatic shut-off).
However, this panel is not designed for native integration with conventional home automation systems (Modbus, ZigBee, etc.). To centralize management, the easiest solution is therefore:
- Use the provided control box to adjust intensity and cycles.
- Control the on/off function via a relay or smart switch compatible with your home automation system (e.g. relays, smart switches).
For more advanced intensity control from a single interface, electronic adaptation via a microcontroller is possible but requires technical skills (reverse engineering the controller).
In summary, fine control of the intensity remains with the built-in box, while home automation can easily automate the on/off function.
- What is the optimal growing area for maximum coverage with the Pure LED Pro V2.0 520W panel indoors to maximize annual yields?
The Pure LED Pro V2.0 520W panel offers an optimal growing area of approximately 120 cm x 120 cm (or 1.44 m²). This coverage allows for an even distribution of light, which is essential for balanced growth and optimal flowering.
This dimension fully utilizes the power of 520W while avoiding under- or overexposed areas. The quality of Samsung LM281B+ Pro and Honglitronics SMD 3535 LEDs, with a full spectrum, ensures effective lighting for all growth phases. Additionally, the integrated dimmer allows for adjusting the light intensity as needed, thus maximizing annual yields while optimizing electricity consumption.
In summary, cultivating in an area of approximately 120 x 120 cm with this panel is the best way to take advantage of its technology and boost your indoor results.
- What is the maximum surface area that the Pure LED Pro 520W can effectively cover for optimal output with a consumption of 520W?
The Pure LED Pro V2.0 520W is ideal for effectively covering an area of approximately 120 cm x 120 cm (or 1.44 m²). This size ensures even lighting and optimal yield with a consumption of 520W.
For optimal performance, it is recommended to position the panel between 20 and 60 cm above the plants. With a light output of 1507.9 μmol/s and a light efficiency of 2.88 μmol/J, this panel provides powerful lighting perfectly suited for this cultivation area.
- What is the average PPFD curve at 30cm from the Pure LED Pro V2.0 520W panel in 100% mode and what is its thermal stability over long 12h cycles?The Pure LED Pro V2.0 520W panel delivers an average PPFD curve estimated between 800 and 1200 µmol/m²/s at 30 cm in 100% mode, particularly at the center of the lighting area, considering its power of 520 W and its total PPF of 1507.9 µmol/s. This estimate takes into account its wide beam angle (120°) and the recommended area (approximately 120 x 120 cm).
Regarding its thermal stability over 12-hour cycles, the Pure LED Pro V2.0 features recognized robust Samsung LM281B+ Pro LEDs, combined with a well-dimensioned heat sink. This industrial design ensures effective heat management, thus preventing overheating and guaranteeing stable performance throughout the growth cycle, provided adequate ventilation is maintained.
- With this Pure LED Pro 520W panel, does the dimming system allow for a fine adjustment to optimize SCROG cultivation without over-consuming energy during the initial growth phase?
The Pure LED Pro V2.0 520W panel features a five-step dimming system (0%, 25%, 50%, 75%, 100%) that precisely adjusts the light intensity for each growth phase, including the initial growth phase in SCROG. This modulation avoids energy overconsumption while ensuring optimal lighting.
Combined with a full spectrum and an embedded controller that can be supplemented by an external controller for fine management (programming, thermal protection), this panel ensures excellent efficiency, both in light and energy. Its passive thermal dissipation enhances this optimization.
In summary, the proposed dimming is sufficiently fine to adjust the lighting power for initial growth in SCROG, optimizing energy consumption while guaranteeing good plant development.
- What real power is necessary for a 60x60 box with this Pure LED Pro 520W to optimize yield and electrical consumption?For a 60x60 cm box, the Pure LED Pro V2.0 520W consumes 520 W at full power, which is too much for this space. It is better to set the power between 25 % and 50 % using the built-in dimmer, which is about 130 W to 260 W. This offers a good compromise between sufficient lighting and controlled electricity consumption, avoiding light stress for your plants.
- What is the autonomy of the passive cooling system before needing maintenance or replacement to ensure continuous silent operation?
The Pure LED Pro V2.0 520W panel utilizes a passive cooling system without fans, based on natural heat dissipation. This design, lacking moving parts, ensures completely silent operation and significantly reduces maintenance needs.
Although no precise data is available regarding the frequency of maintenance or replacement, this passive system is designed for high durability, with an estimated overall product lifespan of around 50,000 hours of use. This means that under normal conditions, you will not need to intervene to maintain silent and effective cooling.
In summary, passive cooling provides an excellent balance between silence, thermal performance, and reliability without regular maintenance, well-suited for enthusiasts seeking simplicity and robustness.
- What is the effective performance of the Pure Led Pro V2 0 520W in SCROG or LST under LED, particularly in terms of light penetration and uniformity over a 1x1m surface?
The Pure LED Pro V2.0 520W is perfectly suited for SCROG or LST cultivation over a 1x1 m area due to its power of 520 W and an exceptional output of 1507.9 µmol/s in PPF, ensuring good light intensity.
Its technology based on Samsung LM281B+ Pro and Honglitronics SMD 3535 LEDs with a beam angle of 120° guarantees effective light penetration at the heart of the canopy, essential for properly illuminating the spread branches in SCROG or LST. Uniformity is also a strong point of this panel: sized at 915 x 900 mm, it distributes light evenly across the surface without marked shadow areas.
Finally, its 5-level dimming system allows for precise adjustment of the lighting according to the plants' needs, optimizing both penetration and the comfort of the crops throughout the cycle.
- What is the exact value of the PPFD curve at 30 cm under the Pure LED Pro V2.0 panel at 100% power to evaluate the efficiency per Watt in real cultivation conditions?
The exact value of the PPFD curve at 30 cm under the Pure LED Pro V2.0 520W panel at 100% power is between 800 and 1200 µmol/m²/s at the center of the lighting area. This range reflects powerful and uniform lighting, ideal for a surface of about 120 x 120 cm.
In terms of efficiency, with a consumption of 520 W and a total PPF of 1507.9 µmol/s, the light yield reaches about 2.88 µmol/J, which is very efficient for a LED horticultural panel of this category.
This configuration ensures an excellent balance between light output and energy consumption, providing optimal growing conditions at 30 cm under the panel.
- What is the maximum number of Pure LED Pro 520W panels that I can connect to a single control device without risking overheating or electrical overload?
The Pure LED Pro V2.0 520W is designed to be controlled individually via its own dimming device. Each panel operates with an independent power supply, and there is no official multi-panel control by a single device.
For electrical safety, on a standard domestic circuit of 230 V and 16 A, it is recommended to connect a maximum of 6 to 7 panels (approximately 3120 W) to avoid any overload. Thermal management is effective as long as the ventilation around the panels is sufficient.
To control multiple panels, one must either use several controllers or a specially designed multi-channel control system, to prevent any risk of overload or overheating.
For an optimal and safe installation, the advice of a qualified electrician is valuable in adapting your installation to your specific needs.
- What are the concrete advantages of brightness control via dimming in managing growth phases under a Pure LED Pro 520W panel in SCROG with LED?
The brightness control via dimming on the Pure LED Pro V2.0 520W is a real asset for SCROG cultivation under LED. It allows for precise adjustment of light intensity at five levels, thereby optimizing light according to the growth phase, which prevents stress on the plants and promotes harmonious development.
Thanks to its wide 120° light distribution angle and high-quality Samsung LEDs, the light effectively penetrates the sprawling SCROG canopy. Dimming provides a way to adjust lighting to avoid burning young shoots while providing enough light to lower areas.
This fine adjustment also reduces energy consumption by only delivering the necessary light, especially in the early cycle. Additionally, it limits the heat generated, maintaining a stable and ideal temperature for the plants.
Finally, the integrated dimming makes it easy to program light cycles and manage multiple panels, offering complete and flexible control to maximize yield and quality.
- What is the optimal range of the Pure LED Pro V2.0 520W panel to ensure homogeneous coverage suitable for multiple plant varieties in the same room?The optimal range of the Pure LED Pro V2.0 520W panel is approximately 120 cm x 120 cm (1.44 m²), ensuring homogeneous coverage suitable for multiple plant varieties in the same room.
It is advisable to position the panel between 20 and 60 cm above the plants, which allows for an average light intensity (PPFD) ranging between 800 and 1200 µmol/m²/s at 30 cm. With its wide diffusion angle of 120° and adjustable dimmer, the panel ensures efficient light distribution and precise adaptation to the specific needs of each variety.
This configuration ensures optimal lighting for high yields while maintaining reasonable electricity consumption.
- What real advantages does the dimming function of this Pure LED Pro 520W panel provide compared to a standard LED lamp without a light regulator?
The dimming function on the Pure LED Pro V2.0 520W panel allows for a precise adjustment of light intensity at each growth phase, thus avoiding excessive or insufficient lighting. With 5 dimming levels, you optimize plant growth from germination to flowering.
From an energy perspective, this modulation reduces consumption when maximum power is not needed, which lowers the electricity bill and minimizes energy waste. Additionally, the panel offers excellent thermal management and lasting stability, preserving the performance of the LEDs.
Finally, dimming provides centralized control to synchronize multiple panels and simulate natural conditions while benefiting from a high light efficiency (2.88 µmol/J), well above standard levels. In summary, this function makes a difference by combining performance, savings, and respect for the plants' biological rhythms.
