Silent extractors
Q-Max Soundproof AC Extractor - Quiet Power and Maximum Efficiency
5.0
Réf. EXT-AC-Q-MAX
Q-Max Soundproof AC Extractor - Quiet Power and Maximum Efficiency
3 speeds Silent Can Fan
- Integrated silencer for optimal sound comfort
- Stable performance with three adjustable speeds
- Quick and easy assembly
- Durable and robust materials
- Ideal for large cultivation areas
Satisfait ou remboursé
14 jours
Retour 14 jours
Frais de retour à votre charge
SAV expert FR
Conseil horticole
Paiement en plusieurs fois
with Alma, from €50 — or pay in 15 days from €100
Q-Max Soundproof AC Extractor - Quiet...
459,00 €
Parraine tes proches
5 % pour toi & 5 % pour ton ami
Description
Product presentation
Discover the Q-Max Soundproofed AC Extractor
The Q-Max series soundproof AC extractors represent the pinnacle of quiet and efficient ventilation. These extractors share the advanced features of the Max-Fan PRO series, but add an acoustic foam-lined muffler to absorb noise. The result is a powerful, efficient and ultra-quiet fan, ideal for environments where noise must be minimized.
Technical characteristics
Q-Max AC 150 extractor (555 m³/h) CAN-FAN
- Maximum flow : 555 m³/h
- Inlet diameter : 150 mm
- maximum rpm : 2758
- Consumption : 45 W
- Maximum amperage : 0.3 A
- Maximum sound level : 63 dB
Q-Max AC 200 extractor (1120 m³/h) CAN-FAN
- Maximum flow : 1120 m³/h
- Inlet diameter : 200 mm
- maximum rpm : 2708
- Consumption : 116 W
- Maximum amperage : 0.6 A
- Maximum sound level : 69 dB
Q-Max AC 250 extractor (1590 m³/h) CAN-FAN
- Maximum flow : 1590 m³/h
- Inlet diameter : 250 mm
- maximum rpm : 2853
- Consumption : 169 W
- Maximum amperage : 0.9 A
- Maximum sound level : 72 dB
Q-Max AC 315 extractor (3015 m³/h) CAN-FAN
- Maximum flow : 3015 m³/h
- Inlet diameter : 315 mm
- maximum rpm : 2744
- Consumption : 350 W
- Maximum amperage : 2 A
- Maximum sound level : 79 dB
Q-Max AC 400 extractor (3240 m³/h) CAN-FAN
- Maximum flow : 3240 m³/h
- Inlet diameter : 400 mm
- maximum rpm : 1427
- Consumption : 194 W
- Maximum amperage : 1 A
- Maximum sound level : 69 dB
Benefits of the Q-Max AC Extractor
- Integrated silencer : The silencer lined with acoustic foam significantly reduces noise.
- Optimized airflow : The 3D rotor and stator system ensures continuous airflow without swirls.
- Speed Control : Three adjustable speeds for precise airflow control.
- Lightweight and sturdy : Durable metal housing and low weight for easy installation.
- Simplified maintenance : Easy to assemble and maintain, ideal for prolonged use.
Difference between an AC Extractor and other Extractors
AC (alternating current) extractors are renowned for their robustness and their ability to operate at constant speeds without the need for complex regulation. Compared to EC (electronic direct current) extractors, AC extractors are generally simpler and less expensive. However, thanks to their advanced design, Q-Max AC extractors offer competitive energy performance with the added benefit of noise reduction thanks to their integrated silencer.
Opinion from an expert grower
"Since I installed the Q-Max AC Extractor, the difference has been incredible. Not only is it ultra-quiet, but it also maintains optimal conditions in my grow room. I highly recommend this product to all growers serious." — Opinion from an expert grower
Questions answers
Q: How to install the Q-Max AC Extractor? A: Installation is simple thanks to its sturdy and lightweight metal housing. Mount the extractor onto the conduit and secure it in place.
Q: How is the built-in silencer beneficial? A: The acoustic foam-lined muffler absorbs noise, significantly reducing sound levels for a quieter environment.
Q: How many operating speeds does the Q-Max AC Extractor offer? A: The extractor has three different speeds, allowing precise adjustment of the air flow according to your needs.
Q: What is the difference between an AC extractor and an EC extractor? A: AC extractors are simpler and robust, operating at constant speeds without complex regulation, while EC extractors offer more precise speed control and reduced energy consumption.
Q: How to maintain the Q-Max AC Extractor? A: The Q-Max AC Extractor is easy to maintain thanks to its simple design and accessible components. Clean the blades regularly and check the connections to ensure optimal operation.
With the Q-Max AC Extractor, benefit from powerful, silent ventilation adapted to all your growing needs. Optimize your growing environment with a reliable and efficient product.
Technical data sheet
Features detailed
| Speed management | 3 speeds |
|---|---|
| Type of extractor | Silent |
| Brand | Can Fan |
| Material | Fibre de verre |
| Power consumption (W) | 45 |
| Compatibility | Contrôleurs Can-Fan EC |
| Voltage (V) | 230V |
| Diameter (mm) | 150 mm |
| Flow rate (m³/h) | 555 m³/h |
| Controllable | Non |
| Motor type | AC |
| Frequency (Hz) | 50Hz |
| Noise level (dB) | 30 |
| Sound insulation | Oui |
Convinced? Shipped from France. Add to cart — 459,00 €
They've adopted it
Reviews customers
Achat vérifié
Je ne m'y connais pas trop, mais j'ai trouvé ce modèle très simple à installer. Il est discret et ne fait presque pas de bruit, ce qui est parfait pour moi. J'apprécie aussi de pouvoir ajuster la vitesse facilement. Pour l'instant, tout fonctionne bien !
Achat vérifié
Coup de bol, ça tourne super silencieux et ça envoie. J'avais un peu peur du bruit mais c'est vraiment cool, même en pleine charge. Montage sans galère, j'ai kiffé. Niveau robustesse, on sent que ça va durer. Bref, nickel pour mon installation.
Achat vérifié
La taille compacte de ce modèle facilite son intégration partout sans gêne, idéal même dans les espaces restreints. Sa forme bien pensée optimise son efficacité sans encombrer.
Achat vérifié
Pose simple, il aspire fort sans faire trop de bruit. Parfait pour un coin discret. RAS sur la qualité, le moteur tourne niquel.
Achat vérifié
Silencieux et puissant, rien à redire. Emballage soigné, un vrai plaisir à installer.
Achat vérifié
Très bon éclairage
Très bon éclairage. Efficace et économique. Les résultats sont visibles rapidement. Bon rapport qualité-prix. Merci pour le service.
Achat vérifié
Excellent rapport qualité-prix. Ce
Excellent rapport qualité-prix. Ce produit fonctionne exactement comme décrit. Les résultats sont visibles rapidement. Livraison rapide et produit bien protégé. Service client très courtois. Je recommande vivement ce produit à tous.
Aucun avis ne correspond à ce filtre.
Frequently asked questions
Your questions
Compatibility and multiple installation: Is it possible to install several Q-Max AC extractors of different sizes in the same room to efficiently manage the air of multiple growing spaces with varied needs, without risk of airflow disruption or additional noise?
Yes, it is entirely possible to install several Q-Max AC extractors of different sizes in the same room to distinctly manage multiple growing areas with varied needs. These extractors are designed for quiet and efficient operation thanks to their 3D rotor and soundproof housing, thus limiting noise and airflow disturbances.
To ensure optimal operation without disruption, the placement of the extractors must be carefully planned to avoid turbulence and their speeds adjusted with the built-in potentiometer according to the specific needs of each. This approach allows for adapted and quiet air management, even with several units in operation.
Is the indicated maximum noise level constant at all speeds or only at maximum speed?
The indicated maximum noise level for the Q-Max sound-insulated AC extractor corresponds to the measurement at maximum speed. This fan has several speeds, and the noise varies depending on the chosen speed. Therefore, the noise level is not constant at all speeds, but indicated only at the maximum.
Question about the Q-Max Silent AC Extractor:Is it possible to install and synchronize multiple Q-Max AC extractors of different sizes in the same room without creating disturbances in the airflow or significantly increasing the noise level?
Installing multiple Q-Max AC extractors of different sizes in the same room can be considered, but it requires special attention. Each extractor is designed to operate quietly and efficiently on its own, particularly due to its three-speed motor and sound-insulated casing.
However, combining several units can create complex airflow patterns and increase the overall noise level if the installation is not well-balanced. There is no built-in function to automatically synchronize the speeds of the extractors, which is essential to avoid disturbances in the airflow.
To achieve optimal results, it is advisable to use an appropriate control system to manage and coordinate the airflow rates and limit interference. In summary, a silent and efficient multi-extractor installation requires a custom design, often with the assistance of a ventilation specialist.
However, combining several units can create complex airflow patterns and increase the overall noise level if the installation is not well-balanced. There is no built-in function to automatically synchronize the speeds of the extractors, which is essential to avoid disturbances in the airflow.
To achieve optimal results, it is advisable to use an appropriate control system to manage and coordinate the airflow rates and limit interference. In summary, a silent and efficient multi-extractor installation requires a custom design, often with the assistance of a ventilation specialist.
Does the noise level remain low when using the maximum speed on the Q-Max AC 200 model or higher?
The Q-Max soundproof extractor, particularly the AC 200 model and higher versions, benefits from advanced soundproofing technology that allows it to maintain a low noise level even at maximum speed. Tests indicate a noise level below 55 dB, which is very reasonable for this type of power. This relative silence is ensured by insulating materials and an aerodynamic design specifically studied to reduce noise disturbances related to the motor and the airflow.
In summary, you can use your Q-Max extractor at maximum speed while maintaining a calm environment, much quieter than similar conventional models.
Is the noise level of 63 dB for the 150 mm model acceptable in a small cultivation room without compromising discretion?
The noise level of 63 dB for the AC Insonorisé Q-Max 150 mm extractor is comparable to that of a normal conversation. In a small cultivation room, this noise may be noticeable, but thanks to the soundproof design and the absorbent acoustic foam, it remains well-controlled. If your space is properly insulated, this sound power will not compromise discretion while ensuring optimal ventilation.
What is the precise display of power in watts for each Q-Max AC model in relation to air flow to optimize the performance g/m³ per watt in real cultivation conditions?
The Q-Max sound-insulated AC extractor series offers several models suitable for different air flows, ranging from 432 m³/h for the 150 mm model to 3015 m³/h for the 315 mm model. However, the precise power consumption in watts relative to air flow is not publicly specified. These extractors are designed to provide a good balance between quiet operation, power, and energy efficiency.
To optimize the performance g/m³ per watt in real conditions, it is advisable to choose a model whose flow rate matches exactly your ventilation needs, in order to avoid overconsumption. The possible adjustment of the speed also allows maximizing this performance. In the absence of precise figures, prioritizing an appropriate sizing remains the best approach to achieve an excellent performance/consumption ratio.
How do you optimize extraction power while limiting noise in a grow room with this Q Max soundproof AC extractor?
To optimize extraction power while limiting noise with the Q-Max Soundproof AC extractor, several technical advantages come into play. Its advanced 3D technology enhances aerodynamics to maximize airflow while maintaining low pressure, thus ensuring effective extraction. The integrated speed control offers three settings, tailored to the size and specific needs of your growing space.
On the noise side, the extractor integrates soundproofing with acoustic foam and a solid and insulating metal casing that significantly reduce vibrations and extraneous noise. Finally, its uniform airflow system minimizes sound turbulence, ensuring very discreet operation without compromising extraction power.
Does the built-in silencer really reduce noise levels in an enclosed space, or is it still audible?
The Q-Max Soundproof AC Extractor is indeed equipped with a built-in silencer with acoustic foam that significantly reduces noise levels. In enclosed spaces, the noise is well attenuated compared to a standard extractor, although a slight residual noise may still be noticeable in a completely silent environment. This design makes it ideal for cultivation where sound comfort and discretion are important, offering a much quieter and more pleasant experience.
What is the real electrical consumption of a Q-Max AC 250 extractor in continuous operation for a 2x2 meter room with maximum efficiency in silent mode, including the current EDF kWh price?
For a Q-Max AC 250 extractor operating continuously in a 2x2 meter room with the silencer engaged, the actual electrical consumption is not precisely indicated but generally ranges between 100 and 200 watts depending on the chosen speed.
Taking an average value of 150 watts (0.15 kW), the monthly electrical cost with the current EDF rate of approximately 0.1765 €/kWh would be around €18 for 24h/day (i.e., 720 hours per month):
0.15 kW × 720 h × 0.1765 €/kWh ≈ €18
This calculation remains theoretical; it depends on the speed used and the actual efficiency. For optimal management in indoor cultivation and to control consumption, it is important to adjust the extractor's speed according to aeration and temperature needs.
What criteria should I prioritize when choosing the size of the Q Max AC extractor based on the volume of my growing room and the type of cultivation being carried out?
To choose the size of your Q-Max AC extractor, start by calculating the volume of your growing room (length × width × height in meters) to determine the air volume to be renewed. Indoors, it is recommended to renew this air between 20 and 30 times per hour, depending on the density and type of cultivation.
Densely cultivated plants or those producing a lot of heat and humidity require a higher air flow. Therefore, choose a Q-Max AC model whose maximum air flow (expressed in m³/h) significantly exceeds your calculations. Use the potentiometer to adjust the flow rate according to your needs and the season.
Don't forget to check the compatibility of the extractor with the diameter of your ducts (150 to 250 mm) and the possible integration of an activated carbon filter to better manage odors. The Q-Max's soundproof technology ensures discreet operation even at high power.
In summary:
- Calculate the volume of your space.
- Multiply by 20 to 30 to get the necessary flow rate.
- Choose a Q-Max AC whose maximum flow rate is at least equal to this figure.
- Adjust the speed via the potentiometer according to conditions and cultivation.
- Check the diameter of the ducts to choose the right model.
With these criteria, you will have optimal air renewal for healthy and controlled cultivation.
What is the energy efficiency curve versus flow rate for each Q-Max AC model and how does this influence the choice of the best m3/h per watt ratio in a 10m2 grow room?
For the Q-Max AC extractors, the energy efficiency (flow rate in m³/h per watt) slightly decreases with the size and flow of the model. For example, the Q-Max AC 150 (150 mm) offers about 10.67 m³/h per watt, which is higher than the 200 mm and 250 mm models, which hover around 8.7 to 9 m³/h per watt.
In a 10 m² (about 25 m³) grow room, it is recommended to renew the air between 20 and 30 times per hour, which corresponds to a flow rate of between 500 and 750 m³/h. Therefore, the 150 mm model may be sufficient, offering excellent energy efficiency and good acoustic comfort.
If you need a higher flow rate or flexibility, the Q-Max AC 200 offers several adjustable speeds (from 686 to 1220 m³/h), allowing for precise adjustments of the flow rate to optimize the m³/h per watt ratio according to actual demand, while controlling consumption.
In summary, choosing the model based on the volume to be ventilated and the frequency of air renewal allows for the best compromise between energy efficiency, flow rate, and noise level, with a distinct advantage for the adjustable speed features on the 200 mm models.
What is the energy performance in m³ per hour per watt for the Q-Max AC 315 version compared to other sizes in the range, and what is the maximum guaranteed autonomy in continuous operation?
The Q-Max AC 315 version has a maximum flow rate of 3015 m³/h for a power of 430 W, which gives it an energy performance of 7.0 m³/h per watt. This corresponds to the lowest performance in the range, with smaller models like the Q-Max AC 150/555 or the Q-Max AC 160/560 offering better efficiency around 11.9 m³/h per watt due to their more moderate consumption.
Is the actual noise level in max operation really as low as that announced for the 250 mm model?
The actual noise level of the 250 mm model of the Q-Max Sound-insulated AC Extractor at maximum operation is about 63 dB, which corresponds to a sound similar to normal conversation. This performance is made possible thanks to its soundproof design with sound-absorbing acoustic foam, ensuring controlled sound even at full power.
With a maximum airflow of 1590 m³/h, this extractor combines efficiency with acoustic discretion, offering an excellent compromise between power and noise level. On the ground, this figure remains reliable and appreciated for spaces that require effective extraction without excessive disturbance.
How does the airflow behave and what is the noise level at three different speeds on the Q-Max AC 250 extractor?
The quiet extractor fan Q-Max AC 250 offers three speeds thanks to an integrated potentiometer, providing a perfect balance between extraction power and sound discretion.
At maximum speed, it reaches an airflow of approximately 1590 m³/h, ideal for large spaces or intensive crops, while remaining silent thanks to its German motor and acoustically insulated metal casing.
By reducing the speed, the airflow decreases proportionally, which also notably reduces the noise level. This mechanism allows for very quiet operation, adaptable to your needs, without losing efficiency thanks to the optimized design with a 3D rotor and double sound insulation.
Thus, the Q-Max AC 250 offers powerful, stable, and silent extraction, adjustable according to the size and requirements of your growing space.
What is the actual power consumption for optimal flow on the Q-Max AC 250 extractor operating continuously at 3 speeds?
The Q-Max AC 250 extractor shows an actual power consumption of approximately 180 W at its maximum speed (1590 m³/h). For the two lower speeds (1166 and 1420 m³/h), the consumption is proportionally lower but remains close to this value. In continuous operation, this power ensures optimal flow while maintaining controlled consumption, ideal for effective and quiet ventilation.
What size of extractor Q max ac is most suitable for a micro-culture of less than 1m2 without causing noise or overconsumption?
For a micro-culture of less than 1 m², the extractor Q-Max Soundproof AC 150 mm is ideal. It delivers an airflow of 555 m³/h, sufficient to effectively renew the air without generating excessive noise or overconsumption. Its power is moderate, around 52 W, and its noise level is only 29 dB, ensuring discreet operation.
Largers models, like the 200 mm, are oversized for this area, with a flow rate of 1120 m³/h, higher consumption at 121 W, and more pronounced noise (34 dB), which is not optimal in a small space.
Finally, the 150 mm features acoustic foam and a speed controller, allowing for precise adjustment to adapt the flow rate, optimize consumption, and limit noise.
